STAINLESS STEEL 309 CNC COMPONENTS GENERAL PROPERTIES:
Alloys 309 and 309S are austenitic chromium-nickel stainless steels that are often used for higher temperature applications. Due to their high chromium and nickel content, Alloys 309 and 309S are highly corrosion resistant, have outstanding resistance to oxidation, and excellent heat resistance while providing good strength at room and elevated temperatures. The only significant difference between 309 and 309S is the carbon content. Alloy 309S has a much less carbon composition which minimizes carbide precipitation and improves weldability.
STAINLESS STEEL 309 CNC COMPONENTS APPLICATIONS:
Alloys 309 and 309S are used exclusively for their high temperature oxidation resistance, excellent high temperature strength, along with their resistance to creep deformation and environmental attack. Some examples include, but are not limited to:
- Heating elements
- Aircraft and jet engine parts
- Heat exchangers
- Carburizing annealing products
- Sulfite liquor handling equipment
- Kiln liners
- Boiler baffles
- Refinery and chemical processing equipment
- Auto exhaust parts
STAINLESS STEEL 309 CNC COMPONENTS CORROSION RESISTANCE:
- Provide excellent corrosion resistance
- More resistant to marine atmospheres than Alloy 304
- Often used at higher temperatures to take advantage of their oxidation resistance
- Have high resistance to sulfite liquors
- Generally considered heat resistant alloys
- Destructive scaling temperature is approximately 2000oF
- Good scaling resistance with regard to continuous and intermittent services
STAINLESS STEEL 309 CNC COMPONENTS HIGH TEMPERATURECORROSION:
Alloy 309 resists high temperature corrosion in most in-service conditions. Operating temperatures are as follows:
- Oxidizing conditions (max. sulfur content–2 g/m3)
- 1922°F (1050°C) continuous service
- 2012°F (1100°C) peak temperature
- Oxidizing conditions (max. sulfur greater than 2 g/m3)
- 1742°F (950°C) maximum temperature
- Low oxygen atmosphere (max. sulfur content–2 g/m3)
- 1832°F (1000°C) maximum temperature
- Nitriding or carburizing atmospheres
- 1562–1742°F (850–950°C) maximum
The alloy does not perform as well as Alloy 600 (UNS N06600) or Alloy 800 (UNS N08800) in reducing, nitriding or carburizing atmospheres, but it does outperform most heat resistant stainless steels in these conditions.
STAINLESS STEEL 309 CNC COMPONENTS FABRICATION:
- Can be roll formed, stamped, and drawn readily
- In process annealing is often required to reduce hardness and increase ductility
STAINLESS STEEL 309 CNC COMPONENTS HEAT RESISTANCE:
- Cannot be hardened through heat treatment because the consist solely of austenite at room temperature
- Higher tensile and yield strengths that can be obtained through cold working and not followed by full annealing are not stable at the higher temperatures where these alloys are used
- Creep properties can be negatively affected by the use of cold worked material at these higher temperatures
STAINLESS STEEL 309 CNC COMPONENTS WELDING CHARACTERISTICS:
- The austenitic class of stainless steels is generally considered to be weldable
- Generally considered to have weldability equivalent to the most common alloys of the austenitic class 304 and 304L
- Special consideration is needed to compensate for a higher coefficient of thermal expansion to avoid warping and distortion
STAINLESS STEEL 309 CNC COMPONENTS CHEMICAL PROPERTIES:
| C | Mn | Si | P | S | Cr | Ni | Fe | |
|---|---|---|---|---|---|---|---|---|
| 309 | max: 0.20 | 2.0 max | 0.75 max | 0.045 max | 0.03 max | min: 22.0 max: 24.0 | min: 12.0 max: 15.0 | Balance |
| 309H | min: 0.04 max: 0.10 | 2.0 max | 0.75 max | 0.045 max | 0.03 max | min: 22.0 max: 24.0 | min: 12.0 max: 15.0 | Balance |
STAINLESS STEEL 309 CNC COMPONENTS MECHANICAL PROPERTIES:
| Grade | Tensile Strength ksi (min) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX |
|---|---|---|---|---|
| 309/H | 40 | 30 | 40 | 217 |
STAINLESS STEEL 309 CNC COMPONENTS PHYSICAL PROPERTIES:
| Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
|---|---|---|---|---|---|---|
| at 68°F: 0.285 | 9.0 at 32- 212°F | 30.7 at 68°F | 28.5 | 8.28 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500-2590 |
| Description: Valve related cnc products and vmc components Material: Stainless steel 202, 304/304L, 316/316L, 304H, 316H, 309/S, 310/S, 317/L, 321/H, 347/H, 904L, 330, 254SMO, 410, Duplex 2205 and 2507. Nickel Alloy such as alloy 200/201, C276, C22, Alloy 400, Alloy 600, Alloy 625, Alloy 800H, Alloy 800HT, 254SMO, AL6XN and Titanium Grade 1, Grade 2, Grade 5 and all other grades in Copper alloys. Size: As per Diagram and requirement Finish: As per requirement Process: CNC swiss, CNC turning, VMC machining, Milling and Grinding. |
Description: Spool CNC components Material: Stainless steel 202, 304/304L, 316/316L, 304H, 316H, 309/S, 310/S, 317/L, 321/H, 347/H, 904L, 330, 254SMO, 410, Duplex 2205 and 2507. Nickel Alloy such as alloy 200/201, C276, C22, Alloy 400, Alloy 600, Alloy 625, Alloy 800H, Alloy 800HT, 254SMO, AL6XN and Titanium Grade 1, Grade 2, Grade 5 and all other grades in Copper alloys. Size: As per Diagram and requirement Finish: As per requirement Process: CNC swiss, CNC turning, VMC machining, Milling and Grinding. |
| Description: Medical Implants, Bone screw, pedicle screws, pins, plates and other implants
Material: Stainless steel 202, 304/304L, 316/316L, 304H, 316H, 309/S, 310/S, 317/L, 321/H, 347/H, 904L, 330, 254SMO, 410, Duplex 2205 and 2507. Nickel Alloy such as alloy 200/201, C276, C22, Alloy 400, Alloy 600, Alloy 625, Alloy 800H, Alloy 800HT, 254SMO, AL6XN and Titanium Grade 1, Grade 2, Grade 5 and all other grades in Copper alloys. Size: As per client’s requirements Finish: As per clients requirements Process: CNC swiss, CNC turning, VMC machining, Milling and Grinding. |
Description: Plugs and Exotic Fasteners with unique designs and sizes Material: Stainless steel 202, 304/304L, 316/316L, 304H, 316H, 309/S, 310/S, 317/L, 321/H, 347/H, 904L, 330, 254SMO, 410, Duplex 2205 and 2507. Nickel Alloy such as alloy 200/201, C276, C22, Alloy 400, Alloy 600, Alloy 625, Alloy 800H, Alloy 800HT, 254SMO, AL6XN and Titanium Grade 1, Grade 2, Grade 5 and all other grades in Copper alloys. Size: As per client’s requirements Finish: As per clients requirements and all types of coating available Process: CNC swiss, CNC turning, VMC machining, Milling and Grinding. |
| Description: Shaft and pins Material: Stainless steel 202, 304/304L, 316/316L, 304H, 316H, 309/S, 310/S, 317/L, 321/H, 347/H, 904L, 330, 254SMO, 410, Duplex 2205 and 2507. Nickel Alloy such as alloy 200/201, C276, C22, Alloy 400, Alloy 600, Alloy 625, Alloy 800H, Alloy 800HT, 254SMO, AL6XN and Titanium Grade 1, Grade 2, Grade 5 and all other grades in Copper alloys. Size: As per client’s requirements Finish: As per clients requirements Process: CNC swiss, CNC turning, VMC machining, Milling and Grinding. |
Description: Precision CNC and VMC sheet metal components, Top Rollers, Spray nozzles, Instrumentation fittings as per drawings Material: Stainless steel 202, 304/304L, 316/316L, 304H, 316H, 309/S, 310/S, 317/L, 321/H, 347/H, 904L, 330, 254SMO, 410, Duplex 2205 and 2507. Nickel Alloy such as alloy 200/201, C276, C22, Alloy 400, Alloy 600, Alloy 625, Alloy 800H, Alloy 800HT, 254SMO, AL6XN and Titanium Grade 1, Grade 2, Grade 5 and all other grades in Copper alloys. Size: As per client’s requirements Finish: As per clients requirements Process: CNC swiss, CNC turning, VMC machining, Milling and Grinding. |
| Description: Aerospace parts such as adapters, flanges, knobs, couplings, fittings, ferrules, brackets, clamps, connectors, hoses, Elbows, Tees, shafts, Nipples, Hex plugs etc Material: Stainless steel 202, 304/304L, 316/316L, 304H, 316H, 309/S, 310/S, 317/L, 321/H, 347/H, 904L, 330, 254SMO, 410, Duplex 2205 and 2507. Nickel Alloy such as alloy 200/201, C276, C22, Alloy 400, Alloy 600, Alloy 625, Alloy 800H, Alloy 800HT, 254SMO, AL6XN and Titanium Grade 1, Grade 2, Grade 5 and all other grades in Copper alloys. Size: As per client’s drawings and requirements Finish: As per clients drawings and requirements Process: CNC swiss, CNC turning, VMC machining, Milling and Grinding. |
Description: Industrial Precision CNC and VMC components for motorsports, automotives, bicycle components, energy and power, oil and gas equipments etc. Material: Stainless steel 202, 304/304L, 316/316L, 304H, 316H, 309/S, 310/S, 317/L, 321/H, 347/H, 904L, 330, 254SMO, 410, Duplex 2205 and 2507. Nickel Alloy such as alloy 200/201, C276, C22, Alloy 400, Alloy 600, Alloy 625, Alloy 800H, Alloy 800HT, 254SMO, AL6XN and Titanium Grade 1, Grade 2, Grade 5 and all other grades in Copper alloys. Size: As per client’s drawings and requirements Finish: As per clients drawings and requirements Process: CNC swiss, CNC turning, VMC machining, Milling and Grinding. |
We export our STAINLESS STEEL 309 CNC COPONENTS products to Western and Eastern Europe, Saudi Arabia, Bangladesh, United States, United Arab Emirates, Canada, Angola, Argentina, Austria, Azerbaijan, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia etc. We are sure that we also can cover the requirements requested by your company you can email us at harshsteel@ymail.com for your instant requirements.
