UNS S31008 Washers, SS 310S Washers, AISI SS 310S Stainless Steel 310S Washers Supplier, Manufacturer and Exporter in India


Din 1.4845 SS 310S Washers, SS UNS S31008 Washers, Stainless Steel 310S Washers, 310S Stainless Steel 310S Washers Suppliers in India.

GENERAL PROPERTIES

Alloy 310 is an austenitic stainless steel that combines excellent high temperature properties with good ductility and weldability. It is typically used for elevated temperature applications as its high chromium and nickel content provide solid corrosion resistance, excellent resistance to oxidation, and superior strength in temperatures up to 2100°F. Due to its high chromium and nickel content, it is superior to 304 or 309 stainless in most environments.


APPLICATIONS

The higher alloyed stainless steels generally have excellent strength at elevated temperatures along with outstanding resistance to creep deformation and environmental attack. Therefore, Alloy 310 is used widely in industries such as heat treatment and chemical processing. Some examples include:


  • Furnace Parts
  • Oil Burner Parts
  • Heat Exchangers
  • Welding Filler Wire and Electrodes
  • Annealing Covers
  • Combustion Tubes
  • Fire Box Sheets

VALUE ADDED SERVICES

  • Need a special length?
    • We can custom level 3/8″ thick x 72″ x 186″ from our plate line to reduce scrap
  • Polish plate inventory available
    • We supply #4, #6, and #8 mirror finish
    • Special polishes available
  • Plate processing
  • Dynamic water jet cutting
  • Plate shearing
  • Saw cutting
  • Plasma cutting and high quality plasma cutting
  • Machine cut rings and discs

Penn Stainless Alloy 310 Plate and Processed Flat Bar provides superior resistance to corrosion and heat exposure, in even the most demanding environments.


CORROSION RESISTANCE

  • Provides excellent corrosion resistance
  • High chromium content allows for good aqueous corrosion resistance
  • Excellent resistance at normal temperatures and also has good resistance to oxidizing and carburizing atmospheres

HEAT RESISTANCE

  • Good resistance to oxidation in intermittent service in air at temperatures up to 1040°C and 1150°C in continuous service.
  • Good resistance to thermal fatigue and cyclic heating.
  • Widely used where sulphur dioxide gas is encountered at elevated temperatures.
  • Continuous use in 425-860°C range not recommended due to carbide precipitation, if subsequent aqueous corrosion resistance is needed
  • Generally used at temperatures starting from about 800 or 900°C – above the temperatures at which 304H and 321 are effective.

FABRICATION

  • Commonly used in the heat treatment and process industries due to high temperature and corrosive environments
  • Often fabricated into complex structures
  • Roller-forms, stamps and draws readily
  • Because 310 work hardens, severe forming operations should be followed by an anneal

WELDABILITY

  • Austenitic stainless steel is generally considered to be weldable
  • Generally considered to have weldability equivalent to 304 and 304L
  • Special consideration is needed to compensate for a higher coefficient of thermal expansion to avoid warping and distortion

CHEMICAL PROPERTIES:

% Cr Ni C Si Mn P S Mo Cu Fe
310 min: 24.0
max:26.0
min: 19.0
max: 22.0
0.25 0.75 2.0 0.045 0.030 0.75 0.5 balance
310S min: 24.0
max: 26.0
min: 19.0
max: 22.0
0.08 1.00 2.0 0.045 0.030 0.75 0.5 balance

MECHANICAL PROPERTIES:

Grade Tensile Strength
ksi (min.)
Yield Strength 0.2%
Offset ksi (min.)
Elongation -
% in
50 mm (min.)
Hardness
(Brinell) MAX
Hardness
(Rockwell B) MAX
310/310S 75 30 40 217 95

PHYSICAL PROPERTIES:

Denstiy
lbm/in3
Coefficient of
Thermal Expansion (min/in)-°F
Electrical Resistivity mW-in Thermal Conductivity BTU/hr-ft-°F Specific Heat BTU/lbm -°F Magnetic Permability (annealed)1 Modules of Elasticity (annealed)2-psi
at 68 °F at 68 – 212°F at 68 – 932°F at 68 – 1832°F at 68°F at 1200°F at 68 – 1832°F at 68 – 932°F at 32 – 212°F at 200H in tension (E) in shear (G)
0.29 8.8 9.5 10.5 30.7 10.5 10.8 0.12 1.02 29 x 106 11.2 x 106

STAINLESS STEEL

Grades 18-8, 303, 304, 304L, 316, 316L, 309, 310, 317L, 321, 330, 347, 410, 420, 430, 17-7PH


BOLTS AND SCREWS


ANSI/ASME B18.2.1, B18.3, B18.5, B18.6.2 ASTM A193, A320, F593, F837, F879, F880
HEX HEAD CAP SCREWS, HEAVY HEX BOLTS, T-HEAD BOLTS, LAG SCREWS
CARRIAGE BOLTS, ELEVATOR BOLTS, WEDGE ANCHOR BOLTS
SOCKET SCREWS: SOCKET CAP, FLAT AND BUTTON HEAD, SHOULDER SCREWS, SET SCREWS

MACHINE AND TAPPING SCREWS

ANSI/ASME B18.6.1, B18.6.3, B18.6.4
MACHINE, SHEET METAL, THREAD CUTTING, SELF-DRILLING

NUTS


ANSI/ASME B18.2.2, B18.17, ASTM A194, F594, IFI 128
JAM, FINISHED, HEAVY, COUPLING, WING, NYLON INSERT, SERRATED FLANGE,
SLOTTED (CASTLE), ACORN (CAP), KEPS

WASHERS


ANSI/ASME B18.21.1, B18.22.1, B18.23.1
FLAT, LOCK, BEVELED, EXTERNAL AND INTERNAL TOOTH, COMPRESSION, SAE

THREADED ROD


ASTM A193, A320, F593, IFI 136
3-6-12 FOOT LENGTHS
STUDS: GENERAL PURPOSE, STUD BOLTS, DOUBLE END, SINGLE END

TURNBUCKLES

BENT BOLTS AND EYE BOLTS


ANSI/ASME B18.15, IFI 136
J-BOLTS, HOOK BOLTS, CLOSED AND OPEN EYE BOLTS, FORGED EYE BOLTS

HINGES, NAILS, PINS AND CHAINS

PIPE SUPPORTS, CLAMPS AND STRAPS MSS-SP58, SP69, FIGURE 137
U-BOLTS, CLEVIS HANGERS, RISER CLAMPS, BEAM CLAMPS, 3-BOLT CLAMPS, SHORT STRAPS


Titanium
Grade Common Name Related Specification
British European ASTM UNS
Grade1 3.7025 B348 R50250
Grade2 3.7035 B348 R50400
Grade3 3.7055 B348 R50550
Grade5 3.7165 B345 R56400
Grade7 3.7235 B348 R52400
Grade11 3.2250 B348 R52250




Titanium fasteners are among the most commonly manufactured at Harsh Steel. Often known for its light weight, titanium also possesses excellent mechanical properties, able to resist hostile environments, and is used commonly in offshore engineering projects.


Duplex
Alloy Common Name Related Specifications
European UNS ASTM/ASME
Alloy 2205 SAF 2205 ® 1.4462 S32205 F60
31803 31803 1.4462 S31803 F51




Harsh Steel produces duplex fasteners in all grades of duplex, to customer specification. Duplex grades are a mixed microstructure of Austenite and Ferrite, combining the properties of both (hence the name DUPLEX). Duplex stainless steels have high corrosion resistance as well as a high strength. Mechanical properties are around double that of a typical austenitic grade such as 316. They would also normally offer higher stress cracking resistance in Chloride solutions for example. They are composed typically of 22% Chromium, 5 % nickel. Having worked with duplex since its outset, the duplex bolting continues to account for a core part of our business, along with Super duplex.

Super Duplex

Alloy Common Name Related Specification
European UNS ASTM/ASME
Alloy 255 Ferralium 255 ® 1.4507 S32550 F61
Zeron 100 Zeron 100 ® 1.4501 S32760 F55
Alloy 2507 SAF 2507 ® 1.4410 S32750 F53




We are proud that Harsh Steel is the world’s number one bespoke producer of Super Duplex bolting. Super Duplex stainless steel grades are similar to standard duplex, but they contain a higher content of Chromium, thus enhancing the corrosion resistance and mechanical properties. Harsh Steel produces fasteners in all three types of Super Duplex.


Stainless Steels / Others
Grade Related Specification
British European ASTM UNS
304/304L BS 970 1.4301/1.4306 A193 B8, A320 B8 S 30400 / S30403
310 BS 970 1.4841 A479 S 31000 S 31008
310S BS 970 1.4845 S 31008
316/316L BS 970 1.4401 A193 B8M, A320 B8M S 31600 / S31603
317/317L BS 970 1.4449/1.4438 S 31700 / S31703
321 BS 970 1.4541 A193 B8T S 32100
347 BS 970 1.4550 A193 B8C, A320 B8C S 34700
410 BS 970 1.4006 S 41000
431 BS 970 1.4057 S 43100
174PH 1.4562 S 14700
660 A/B/C/D 1.4980 A453 K 66286
254 SMO ® 1.4547 S 31254
C63000 B150 C63000
904L 1.4539 N08904
Zirconium 702 R60702
Zirconium 705 R60705




Harsh Steel started off producing Stainless Steel bolting in its formative years, and although the company has since diversified into more exotic materials, we continue to offer Stainless Steels and they continue to be an important part of our business, especially if customers require non-standard bolting: i.e. non-standard sizes, special specification, or otherwise difficult to find. We offer all grades of stainless steels, be it Austenitic, Ferritic or Martensitic.


High Nickel Alloys
Alloy Common Name Related Specification
British European ASTM UNS
Alloy 600 Inconel 600 ® BS 3076 NA 14 2.4816 B166 N06600
Alloy 601 Inconel 601 ® 2.4627 B166 N06601
Alloy 625 Inconel 625 ® BS 3076 NA 21 2.4856 B446 N06625
Alloy 718 Inconel 718 ® 1.4668 B637 N07718
Alloy 750 Inconel 750 ® 2.4669 B637 N07750
Alloy 400 Monel 400 ® BS 3076 NA13 2.4360 F467 N04400
Alloy K500 Monel K500 ® BS 3076 NA18 4.4375 B865-04 N05500
Alloy C276 Hastelloy C276 ® 2.4819 B574 N10276
Alloy 22 Hastelloy C22 ® 2.4602 B574 N06022
Alloy B2 Hastelloy B2 ® B335 N10665
Alloy X Hastelloy X ® 2.4655 B572 N06002
Alloy B3 Hastelloy B3 ® 2.4600 B335 N10675
Alloy G30 Hastelloy G30 ® 2.4603 B581 N06030
Alloy 50 Nitronic 50 ® A479 XM-19 S20910
Alloy 60 Nitronic 60 ® A193 B8S S21800
Alloy 75 Nimonic 75 ® 2.4951 B637 N06075
Alloy 80A Nimonic 80A ® BS 4882 NA20 2.4952 B637 N07080
Alloy 90 Nimonic 90 ® B408 N07090
Alloy 800 Incoloy 800 ® BS 3076 NA15 1.4876 B408 N08800
Alloy 800H Incoloy 800H ® B408
Alloy 800 HT Incoloy 800HT ® 1.4959 B408 N08811
Alloy 825 Incoloy 825 ® BS 3076 NA16 2.4858 B425 N08825
Alloy 925 Incoloy 925 ® B805 N09925
Alloy DS Incoloy DS ® BS 3076 NA17 1.4862 N08330




Harsh Steel’s substantial experience in working with high nickel alloys bolting is crucial as they are extremely difficult materials to machine and can require various forms of additional treatment to ensure full conformity. Related by their high percentage of nickel in their composition, these highly corrosion-resistant materials are widely used in the petrochemical and offshore sector, and are often better known by their registered trade names (e.g. Inconel®, Hastelloy®, Monel® and Nimonic®).


INCONEL  BOLTS

We produce inconel fasteners in several grades. Inconels are austenitic nickel-chromium superalloys. They are used in extreme environments, often in gas turbines, nuclear reactors and natural gas processing plants.


HASTELLOY BOLTS

Hastelloy bolts & nuts can be most effective under high temperatures and corrosive environments, with high stress resistance.


MONEL  BOlTING

HARSH STEEL manufactures Monel fasteners in A400 and K500. Monel grades are nickel-copper based alloys and have high corrosion resistance and strength properties. They are often used in valves, pumps and heat exchangers.


INCOLOY  BOLTS

HARSH STEEL produces various grades of Incoloy bolts & nuts. Another of the superalloys, it is used in extreme environments.


NITRONIC BOLTS

Nitronic grade fasteners have excellent corrosion resistance properties and strength. It has low magnetic permeability and excellent cryogenic properties.



Harsh Steel has released it own special Super Duplex Fastener Specification Our range of fasteners are manufactured using quality material that are known for high tensile strength and durability. These industrial fasteners are offered with Manufacturer Test Certificate as per EN 10204 / 3.1B. We offer industrial fasteners in different grades such as industrial washers, industrial screws, stainless washers and stainless screws. Available in different sizes, our range of fasteners can be customized as per the specifications of our clients.


Stainless Steel Fasteners

Harsh Steel is amongst the leading manufacturers of quality Stainless Steel Fasteners. These industrial stainless steel fasteners are made using top grade rust resistant steel to provide long life service. Widely used in different industries like defense industry, shipbuilding industry, chemical industry, fertilizer industry, petrochemical industry, refineries and steel plant, these industrial stainless steel fasteners are available in various grades and sizes as per the requirements of our clients.

Specifications


  • Standard : ASTM / ASME A/SA 193 / 194
  • Grade : B 8 (304), B 8C (SS 347), B 8M (SS 316), B 8 T (SS 321), A 2, A 4


Form


  • Bolts : Bolts stud bolts, hex head bolts, socket hexagon head screw anchor bolts, u-bolts, J bolts, mushroom head square neck bolts, t- head bolts, wing screw, eye bolt, eye bolt, foundation bolts and structural bolts
  • Washer : Plain washer , plain big & small OD washer , spring lock washer , spring washer heavy duty , tooth washer , star washer , tab washer with one & two tab
  • Nuts : Hexagon nuts, hexagon coupling nuts, hexagon thin nut, square nut, hexagon castle nuts, self locking nut, hexagon domed cap nuts
  • Screw : Pan head slotted screws, cheese head slotted screws, countersunk head slotted screws, countersunk raised head slotted screws, pan phillipse head screw, countersunk Phillipse raised head screws, slotted cheese trim head machine screws, socket head allen cap screws, allen countersunk socket head cap screws, socket head shoulder screws, socket head cap screw low head, hexagon socket set screw with flat point, hexagon socket set screws with cone point, hexagon socket set screw with dog point, hexagon socket set screws with dog point, hexagon socket set screws with cup point, imprial socket cap screws
  • Other : Threaded rod, as per drawing and customers spec. coating, hot dipped galvanizing, phosphate, Teflon, xylon, zinc, cadmium.

We export our STAINLESS STEEL 310S WASHERS products to Western and Eastern Europe, Saudi Arabia, Bangladesh, United States, United Arab Emirates, Canada, Angola, Argentina, Austria, Azerbaijan, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia etc. We are sure that we also can cover the requirements requested by your company you can email us at harshsteel@ymail.com for your instant requirements.
